EP Solar 10A 12/24V Dual Battery Solar Controller
EP Solar 10A 12/24V Dual Battery Solar Charge Controller
Dual battery controller for the charging of two separately wired 12V or 24V batteries.
Supports simultaneous charging of two batteries.
Charges battery types Sealed Lead Acid, GEL and Flooded
Short circuit protection.
Reverse discharge protection.
Reverse polarity protection.
Controller Specification
Rated charging current: 10 Amps
Rated Voltage: 12V or 24V
Maximum solar input: 120W
Maximum voltage input: 12V Batteries 30V
Maximum voltage input: 24V Batteries 55V
Self consumption: 4mA at night. 10mA when charging
Dimensions: 153 x 76 x 37mm
Please note Only charges 12V or 24V batteries. Does not charge a 12V and 24V battery
